Pružina tažná 1x8x200x187

Volna dlzka L0= 200.00+-[2.80-5.60] mm Drot pruziny d= 1.000 mm 2. Patentovany drot EN 10 270-1 Pomer vinutia i= 7.000 Ma platit! 4 <= i <= 16 Pocet zavitov n= 187.00 zavitov Dlzka oka pruziny o= 6.000 mm >> Vonkajsi priemer << >> Stredny priemer << >> Vnutorny priemer << D1= 8.000+-[0.25-0.50] mm D= 7.000 mm D2= 6.000+-[0.25-0.50] mm >> Dlzka L << >> Sila F << >> Napatie Tau << L0= 200.00 mm F0= 3.50 N L1= 300.00 mm F1= 19.19+-[1.00-2.00] N Tau1= 410.4 Mpa L8= 420.00 mm F8= 38.01+-[1.62-3.25] N Tau8= 813.1 Mpa L9= 512.94 mm F9= 52.59 N Tau9= 1125.0 MPa TauD= 1125.0 MPa Tuhost pruziny c= 3.657 N/mm Stupanie pruziny t= 1.00 mm Rozvinuta dlzka l= 4145.3 mm
